$12.00

SKU: 1601518077426 Brand:

Description

The DELTA AFB0824GHE-WYA is an industrial-grade DC axial flow cooling fan engineered for extreme thermal management in high-density electronic architectures. Manufactured to Original Engineering standards, this 80mm unit delivers exceptional volumetric airflow and static pressure, making it a critical component for preventing thermal throttling in mission-critical hardware.

Technical Specifications:
Brand: Delta Electronics
Model Number: AFB0824GHE-WYA
Equipment Type: DC Axial Flow Cooling Fan
Frame Dimensions: 80 x 80 x 38 mm
Nominal Voltage: 24V DC
Operating Voltage Range: 14.0V to 27.6V DC
Maximum Airflow: 99.01 CFM (2.80 m³/min)
Rated Speed: 6800 RPM
Bearing System: Double Ball Bearing
Housing Material: UL 94V-0 Thermoplastic
Impeller Material: UL 94V-0 Thermoplastic
Acoustic Noise Level: 62.0 dB(A)
Power Consumption: 22.8 W
Operating Temperature Range: -10°C to +70°C
Weight: 156 g

Application and Integration:
This cooling fan is specifically designed for integration into telecommunications infrastructure, enterprise server racks, and automated industrial control cabinets. The high-RPM double ball bearing mechanism ensures extended operational longevity and reliable performance in continuous 24/7 duty cycles. Its robust thermoplastic chassis resists environmental degradation while maintaining precise rotor alignment under high-vibration conditions.

Procurement and Lifecycle Value:
Verified Technical Compatibility with OEM and ODM thermal systems guarantees seamless integration and immediate restoration of cooling capacity. Contact our procurement team to confirm current Lead Time and secure authentic replacement components for your maintenance schedule.

Key Attributes
Voltage: 24v
Material: Plastic
Speed: 6800rpm
Mounting type: Other
Type: Axial flow fan
Warranty: 1 year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball bearing
Customized support: ODM, OEM
After-sales service provided: Online support
Place of origin: Guangdong, China
Brand name: Delta
Model number: AFB0824GHE-WYA
Noise: 54dB-A
Current: 0.65A

Packaging and Delivery
Selling Units: Single item

DELTA AFB0824GHE-WYA Axial Fan Double Ball Bearing Plastic 80x80x38MM 24V DC 99.01CFM 6800RPM

DELTA AFB0824GHE-WYA Axial Fan Double Ball Bearing Plastic 80x80x38MM 24V DC 99.01CFM 6800RPM

DELTA AFB0824GHE-WYA Axial Fan Double Ball Bearing Plastic 80x80x38MM 24V DC 99.01CFM 6800RPM

DELTA AFB0824GHE-WYA Axial Fan Double Ball Bearing Plastic 80x80x38MM 24V DC 99.01CFM 6800RPM

DELTA AFB0824GHE-WYA Axial Fan Double Ball Bearing Plastic 80x80x38MM 24V DC 99.01CFM 6800RPM

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
