Sanyo 9GA0812P4J001 12V Low Power PWM Chassis Axial Fan

Sanyo 9GA0812P4J001 12V Low Power PWM Chassis Axial Fan

$19.40

SKU: 1601005769000 Brand:

Description

The Sanyo Denki 9GA0812P4J001 is a high-performance, low power consumption DC axial cooling fan engineered for demanding thermal management applications. Utilizing Original Engineering from Japan, this 80x25mm chassis fan integrates advanced Pulse Width Modulation (PWM) control, allowing precise speed regulation to optimize both cooling efficiency and acoustic performance.

Technical Specifications:
Brand: Sanyo Denki
Model Number: 9GA0812P4J001
Fan Type: DC Axial Cooling Fan
Frame Size: 80 mm x 80 mm
Frame Thickness: 25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 10.8 VDC to 13.2 VDC
Rated Current: 0.6 A
Maximum Airflow: 73 CFM
Maximum Static Pressure: 177.6 Pa
Sound Pressure Level (SPL): 48 dB(A)
Operating Temperature Range: -20°C to +70°C
Control Method: PWM (Pulse Width Modulation)
Frame Material: High-grade Plastic
Blade Material: High-grade Plastic
Mounting Type: Free Standing
Weight: 110 g
Core Components: Motor, Bearing
Country of Origin: Japan

Industrial Application:
Technical Compatibility is guaranteed for high-density electronic enclosures, manufacturing plant control cabinets, and telecommunications equipment. In scenarios where continuous operation and thermal stability are critical, such as PLC enclosures in automated production lines or machinery repair shops, the 9GA0812P4J001 provides targeted heat dissipation. Its PWM capability ensures that the fan speed scales dynamically with system thermal loads, mitigating thermal throttling, reducing overall energy consumption, and extending the operational lifespan of sensitive internal components.

Procurement and Logistics:
We ensure a streamlined procurement process with optimized Lead Time for global industrial facilities. Single unit packaging measures 21x21x12 cm with a gross weight of 1.000 kg, ensuring secure transit and immediate deployment upon arrival.

Key Attributes
Voltage: 12V
Mounting type: Free Standing
Warranty: 1 Year
Blade material: Plastic
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Japan
Brand name: Sanyo Denki
Model number: 9GA0812P4J001
Frame thickness [mm]: 25
Frame size [mm]: 80
Rated current [A]: 0.6
Max. airflow [CFM]: 73
Operating temperature: -20~+70
Mass [g]: 110
Frame material: Plastic
Operating voltage range [V]: 10.8~13.2
SPL [dB(A)]: 48
Max. static pressure [Pa]: 177.6
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Core Components: Motor, PLC, Bearing, Engine

Packaging and Delivery
Selling Units: Single item
Single package size: 21X21X12 cm
Single gross weight: 1.000 kg

Sanyo 9GA0812P4J001 12V Low Power PWM Chassis Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
